General Description
Our string wound cartridges are manufactured with tructured open outer layers and tight
inner layers to offer true depth filtration for high dirt holding capacity and extremely low
media migration.The main advantage of the string wound filter cartridge is its exceptionally
high structural strength,therefore,they can withstand higher PSID and severel operating
conditions.It can remove contaminant effectively,such as suspended substance,rust and
particulate.
APPLICATIONS
• R.O Filtration
• Medicinal Reagent,Water partical removal
Specifications
| Removal ratings | 1=1μm 3=3μm 5=5μm 10=10μm 25=25μm 50=50μm 75=75μm 100=100μm |
| Media | PP Yarn,Degreasing Cotton,Glass Fiber |
| Support | PP,Stainless Steel |
| Outer Diameter | 63mm,115mm |
| Inner Diameter | 28mm,30mm |
| Max. Operating temperature | Degreasing Cotton+PP Core:60ºC PP Yarn+PP Core:60ºC Degreasing Cotton+Stainless Steel Core:120ºC Glass Fiber+Stainless Steel Core:200ºC |
| Max. Operating DP | 2.0bar/25ºC |
Order Information
For example:
PAA0.22R10S
Rating:0.22um, 222/fin/SS,Length: 10",seal material:Silicone
